Headphone amplifier with DAC

FiiO BTR3K Black

no reviews

AED 329

Product code: 105664

CHAT WITH US

10:00-22:00

Available in stores

    Delivery from the supplier's remote warehouse.
    We will contact you within 48 hours to clarify the delivery time.

    Description

    FiiO has introduced a new version of its compact Bluetooth receiver and headphone amplifier, the BTR3K. It is designed for those who are unsatisfied with the sound of wireless headphones and want to continue using their favorite in-ear monitors in a wireless format.

    Inside the miniature body, it is equipped with the Qualcomm Bluetooth CSR8675 chip, providing support for all major codecs, including high-fidelity ones such as SBC, AAC, AptX, AptX HD, AptX Low Latency, and LDAC. Additionally, the model can simultaneously connect with two wireless audio sources. The built-in diodes on the FiiO BTR3K light up in different colors depending on the codec being used.

    The dual digital-to-analog converter AK4377A is responsible for converting the digital signal to analog, and it features two outputs for headphones – a balanced 2.5mm and a regular 3.5mm. The voltage on the balanced output reaches 78mV when paired with a 32-ohm load.

    The battery life lasts approximately 11 hours when using the AAC codec (Advanced Audio Coding, a multi-channel audio encoding algorithm that supports streaming). The USB-C port is not only used for charging but also for receiving audio signals in the 16-bit/48kHz PCM format (read more about the format in our blog article).

    Features:

    • The model can simultaneously connect with two wireless audio sources.
    • The built-in diodes light up in different colors depending on the codec being used.
    • Two headphone outputs – a balanced 2.5mm and a regular 3.5mm.
    • Built-in omnidirectional microphone.
    • High-speed Bluetooth 5.0.
    • Approximate battery life on a single charge - up to 11 hours.
    • Battery level indication.

    Package Contents:

    • Amplifier.
    • Charging cable.
    • Documentation.

    Characteristics

    • Brand
    • Headphone output
      3.5mm jack, 2.5mm jack
    • Output connectors
      USB-C
    • DAC chip

      The chip used for digital-to-analog conversion

      Glossary of terms
      CSR8675
    • DAC bit depth, bits
      16
    • Powered by USB
      yes
    • Connecting to a computer via USB
      yes
    • Built-in battery
      yes
    • The lowest frequency, Hz
      20
    • The highest frequency, kHz

      The upper limit of the frequencies reproduced by the device. The human ear hears the standard frequency range: 20 Hz – 20000 Hz.

      Glossary of terms
      40
    • Bluetooth version

      Bluetooth is a short-range wireless technology that allows you to connect headphones or portable speakers, a stereo system or a soundbar to your smartphone or laptop. For a certain version to work, both devices must support it. The versions differ in data transfer speed, power consumption, securing data transfer, anti-interference ability and range of connection.

      Glossary of terms
      5.0
    • Color
    • Form factor
      portable
    • Input connectors
      3.5mm jack, 2.5mm jack, USB-C
    • Internal DAC
      yes
    • Material
      plastic
    • Playback via USB
      yes

      Playing music files via USB

      Словарь терминов
    • Circuit design
      discrete

      The circuit with transistors used.

      Словарь терминов
    • Depth, mm
      11
    • Height, mm
      58
    • Width, mm
      25
    • Weight, g
      23.5
    • Service life, months
      24
    • Warranty, months
      12
    • Show all characteristicsShow fewer characteristics
