The RME M-32 AD Pro II is a 32-channel high-end AD converter with AVB support, MILAN certification, designed for the most demanding professional audio applications. It delivers sound conversion with exceptional accuracy and transparency, offering 24-bit/192 KHz quality and fully balanced circuitry. This converter is ideal for large-scale recording studios, broadcast centers, and concert venues where a maximum number of high-quality analog inputs integrated into modern AVB and MADI audio systems is required.
The M-32 Pro II series is designed to meet the high demands of professional studios, immersive sound installations, live sound systems, and industrial applications that require a reliable solution for analog conversion using high-quality network audio processing. These new converters are available with 32 analog inputs or outputs, as well as Dante or AVB for a choice of four different models.
The new M-32 Pro II series, equipped with a 32-channel MADI I/O interface (coaxial and optical with an additional SPF module), improved features with extremely low THD values, intelligent channel routing, and innovative ease of use, truly meets the modern requirements for exceptional audio performance.
Ideal Solution for High-Quality Network Audio Processing
The latest 32-channel M-32 Pro II is based on the most advanced high-resolution converter components and fully balanced analog circuitry, providing a signal-to-noise ratio of 120 dB (A) with very low latency, making the converters industry-leading. While the M-32 AD Pro II provides the same outstanding analog characteristics as its predecessor, the DA converter even improves THD + N to -111 dB. All models benefit from optimized impulse response at a sampling frequency of 88.2 kHz and above, minimizing signal distortion during conversion.
AVB Technology - 2 Fully Redundant Network Ports
In addition to two MADI I/O interfaces with separate signal routing, the new M-32 DA Pro II and M-32 AD Pro II are equipped with an AVB interface based on open IEEE 802.1 and 1722.1 network standards, allowing the transmission of 32 analog channels at a maximum sampling frequency of 192 kHz through a single Ethernet cable. In combination with external AVB switches, the new M series converters can be quickly, easily, and reliably integrated into complex network structures thanks to comprehensive time-synchronous signal processing using the AVB protocol. In total, AVB can transmit and receive up to 128 audio channels at a 48 kHz frequency (96 @ 96k, 64 @ 192k) in all streams.
RME offers an AVB device with two fully redundant network ports, developed in accordance with MILAN recommendations. The RME AVB core carefully implements IEEE standards for the streaming of audio, detection, and control, allowing RME devices to be discovered and fully controlled using any AVB controller, eliminating manufacturer-dependent control protocols. Any signal entering the M-32 Pro II can be directed and transmitted in stream mode over the network with fixed delay and guaranteed bandwidth - no switch configuration needed!
Analog-Level Performance
To ensure maximum compatibility with a variety of analog equipment, the individual channels of the M-32 AD Pro II and M-32 DA Pro II can operate at different line levels - each with full converter resolution. In addition to +19 dBu and +13 dBu, the new M series is one of the few solutions available on the market that also allows operation with SMPTE recommendation +24 dBu at 0 dBFS.
Package includes:
- AD converter
- Power cable
- Mounting kit
- Manual
