Network filter
Furutech e-TP80S NCF Silver Black

Product code: 141937
no reviews

Description

Reviews (0)

Description

Furutech e-TP80S

The Furutech e-TP80S is a sophisticated and extremely well-designed power source that addresses many common issues with audio and video devices caused by low-quality power sources. The shape of the AC waveform is heavily distorted due to ground noise, voltage spikes and drops, high-frequency power supply noise from other devices in your electrical network, and high-frequency digital noise generated by processors and digital connections.

Features:

  • AC input voltage: 250 V, 50/60 Hz;
  • Fuse current: 10 A;
  • Maximum power: 2500 W;
  • Automatic voltage surge protection;
  • Maximum AC voltage: 1500 V;
  • Peak voltage 6000 V;
  • Noise filter: -20 dB ~ 92 dB (2~100 MHz);
  • Housing material: aluminum;
  • Outlets: Furutech FI-E30(G);
  • IEC connector: Furutech FI-06(G).

The new e-TP80S series from Furutech also features a high-quality filter and MOV circuit: an electromagnetic noise filter and surge protection. Voltage fluctuations and spikes can damage sensitive electronic devices. The surge protection circuit provides an effective response to protect your system. During a voltage spike, the MOV circuit automatically disconnects the EMI filter line power on the main board to prevent potential short circuits. This MOV circuit also suppresses any electrical and mechanical resonance caused by electrical resistance, heat, and energy flow. For your convenience, LEDs indicate normal operation of the surge protection and electromagnetic noise filter functions. When the LEDs are lit, you are protected from noise and voltage spikes.

Package includes:

  • Power filter;
  • Documentation.
Reviews (0)

There are no reviews for this product yet.

Characteristics

Characteristics

Brand
Color
Max current, A
15
Number of sockets
8
Peak power, W
1800
Depth, mm
130
Height, mm
60
Width, mm
400
