With the LiveTrak L-12, you can finally mix, record, and monitor with just one device. This is the only digital console that allows you to mix live performances and record on 12 discrete channels, simultaneously creating up to five independent monitor mixes.
Easy Live Sound Mixing
Each of the 12 discrete channels (8 mono, 2 stereo) features its own three-band parametric EQ and 16 built-in send effects. 8 mono channels also come with a dedicated compressor. Keep track of all parameters with the 12-segment LED indicator, making working with the LiveTrak L-12 simple and intuitive.
Record and Mix Anywhere
The LiveTrak allows you to record audio on 12 discrete tracks in up to 24-bit/96 kHz WAV quality on an SD card while simultaneously mixing your live performance. Tracks are recorded without EQ or effects, so you can transfer them to your digital audio workstation (DAW) for further mixing and editing.
Five Independent Monitor Mixes
Each of the five monitor outputs on the LiveTrak allows you to create a unique mix, allowing each performer to create and save a mix tailored to their personal preferences. The headphone amplifier ensures clear sound in any conditions and eliminates the need for additional monitoring equipment.
Best Mic Preamps
The LiveTrak L-12 features state-of-the-art microphone preamps with an unprecedentedly low noise level (-128 dBu EIN) and maximum input gain up to +60 dB.
Automatic Recording
Automatically record audio with customizable commands for audio inputs. Start recording when the main fader detects a certain sound level in dB or use a specific guitar chord or drum sound as a signal to begin recording. Save data two seconds before recording starts in case your performance begins earlier than planned.
Features:
- 12 discrete channels (8 mono and 2 stereo) with XLR and 1/4" jacks
- Simultaneous recording on 14 tracks, playback on 12 tracks
- Audio interface mode (14 inputs/4 outputs)
- 5 headphone outputs with the ability to create and save up to five monitor mixes
- Use click tracks and backing tracks from your computer in live performances or recordings
- 48V phantom power (channels 1-4 and 5-8)
- High impedance (Hi-Z) input (channels 1 and 2)
- 26 dB PAD (channels 3-8)
- Built-in compressor (channels 1-8)
- Digital level indicator from -48 to 0 dB
- Master Mute button
- High-pass filter
- Stereo panning
- Master and Monitor A-E outputs
- Scene preset function (up to 9 scenes)
- 16 built-in Delay and Reverb effects with customizable parameters
- Built-in talkback microphone
- iOS device compatibility mode
- SD card slot
- Built-in metronome
- Automatic recording start/stop
- Project protection
- Import/export projects via USB 2.0 port
- Analog-to-digital conversion delay adjustment
- Zoom FS01 pedal compatibility
Package Includes:
- Mixer console
- Power adapter (AD-19)
- USB 2.0 cable
- Manual
