RME M-32 DA Pro II-D is a top-notch 32-channel digital-to-analog converter with a 192 kHz sampling frequency, designed specifically for professional recording studios, immersive audio installations, live sound systems, and industrial applications. The M-32 DA Pro II-D boasts impressive technical specifications, extremely low THD values, intelligent channel routing, and ease of use. You get a full range of connectivity options, including 32 analog outputs, 64 Dante input-output channels, and 128 MADI input-output channels, as well as word clock and MIDI input-output functions. You can control the system directly from the front panel of the M-32 DA Pro II-D or configure it over the network using a user-friendly web interface. The RME M-32 DA Pro II-D features three-color backlit channel indicators, peak/RMS metering, redundant power supplies, synchronization and ICC, a protective lock, and a stylish dark mode. Engineers in need of a reliable solution for analog conversion, as well as high-quality audio network processing, will find endless possibilities with the RME M-32 DA Pro II-D.
The M-32 Pro II series is designed to meet the high demands of professional studios, immersive audio installations, live sound systems, and industrial applications requiring a reliable solution for analog conversion with high-quality audio network processing. These new converters are available with 32 analog inputs or outputs, as well as Dante or AVB for selection from four different models.
The new M-32 Pro II series, equipped with a 32-channel MADI input-output interface (coaxial and optical with an additional SPF module), improved with extremely low THD values, intelligent channel routing, and innovative ease of use, truly meets the modern requirements for exceptional sound quality.
Ideal solution for high-quality audio network processing.
The latest 32-channel M-32 Pro II is based on state-of-the-art high-resolution converter components and a fully balanced analog circuit, providing a signal-to-noise ratio of 120 dB (A) with very low latency, making the converters class-leading. While the M-32 DA Pro II provides the same outstanding analog characteristics as its predecessor, the DA converter has even improved THD +N to -111 dB. All models benefit from optimized impulse response at a sampling frequency of 88.2 kHz and above, minimizing signal distortion during conversion.
AVB technology - 2 fully redundant network ports.
In addition to two MADI input-output interfaces, with separate signal routing, the new M-32 DA Pro II and M-32 AD Pro II are equipped with an AVB interface based on open IEEE 802.1 and 1722.1 network standards, allowing for the transmission of 32 analog channels with a maximum sampling frequency of 192 kHz over a single Ethernet cable. In combination with AVB external switches, the new M series converters can be quickly, easily, and reliably integrated into more complex network structures thanks to comprehensive time-synchronous signal processing via AVB protocol. In total, AVB can transmit and receive up to 128 audio channels at a frequency of 48 kHz (96 @ 96k, 64 @ 192k) in all streams.
RME offers an AVB device with two fully redundant network ports, designed in accordance with MILAN recommendations. The RME AVB core meticulously implements IEEE standards for audio streaming, discovery, and control, allowing RME devices to be discovered and fully controlled using any AVB controller, with manufacturer-specific control protocols becoming a thing of the past. Any signal received by the M-32 Pro II can be directed and transmitted in streaming mode over the network with fixed delay and guaranteed bandwidth - no switch configuration required!
Analog-level performance.
To ensure maximum compatibility with a variety of analog equipment, individual channels of the M-32 AD Pro II and M-32 DA Pro II can operate at different line levels - each with full converter resolution. In addition to +19 dBu and +13 dBu, the new M series is one of the few solutions available on the market that also allows operation at the SMPTE +24 dBu recommendation at 0 dBFS.
Package includes:
- DA converter
- Power cable
- Mounting kit
- Manual.
