Acoustic system Magnat Signature 903
The Magnat Signature 903 is the "younger" model in the 900 series.
Features:
- High-frequency module with dual driver with Hi-Res certification and two fmax diffusers;
- 3-way speaker with Bass Reflex phase inverter design;
- Low and midrange driver with ceramic-aluminum membrane and aluminum alloy baskets;
- Supports for safe installation and acoustic isolation.
This is a shelf-mounted three-way speaker with one low-frequency driver and a phase inverter. The Klippel-optimized design features vented cast frames for the LF and MF drivers. The ceramic-aluminum sandwich diaphragms are equipped with inverted dust caps. The speakers are unified by a phase- and amplitude-optimized crossover APOC with high-quality internal wiring and output to a massive terminal panel with sealed connectors.
The low and midrange drivers in the Magnat Signature 900 series are made of an aluminum alloy with ceramic-aluminum membranes. The carefully chosen materials ensure maximum suppression of unwanted vibrations on one hand, and optimal weight on the other. This means that the powerful Neodym technology drivers can reproduce extremely dynamic music while maintaining stable membranes and preventing distortion. The solid aluminum alloy speaker baskets guarantee the necessary stability behind the scenes.
The module made of cast aluminum responsible for incredible sound in the high-frequency range features two fmax HF speakers, certified by the Japan Audio Society with the Hi-Res stamp. The 30mm diffuser with an exceptionally wide surround allows it to seamlessly connect to the midrange. An additional 20mm super high-frequency diffuser forms the basis for extended high-frequency reproduction. Even if many sources do not provide frequencies that high, the upper harmonics are essential for an immersive listening experience. Plus, the diffuser has excellent omnidirectional radiation and precisely calculated sound guides on the front panel for perfect sound spaciousness.
The system allows for either bi-wiring or bi-amping using cable jumpers. The drivers are protected by a removable fabric grille with hidden magnetic fixation. With a nominal (maximum) power of 120 (180) W, the Magnat Signature 903 speaker system, according to the manufacturer, demonstrates a sensitivity of 91 dB and a lower limit down to 30 Hz.
Package includes:
- 2 acoustic systems;
- Documentation.
