Mackie Onyx16 – a 16-channel analog mixer with per-channel recording, effects processor, and USB.
Studio Command
With Studio Command, navigating through the effects block parameters, recording to an SD card, and playback have never been easier. Browse files on the memory card using the built-in display. Additionally, physical buttons for Previous, Next, Record, and Play or Pause are available. Save up to 6 user FX presets and easily recall them.
Backlight
The Mackie Onyx16 mixer features easily readable buttons that brightly illuminate in the dark, so you will always know what is happening with your mix. Additionally, the full-color Studio Command display makes setup and control easier.
Perkins Equalizer
To create the Perkins equalizer, Cal Perkins started with the topology of the Wien Bridge circuit – a highly musical design inspired by respected "British" consoles of the 60s and 70s. Essentially, this design forsakes frequency cutting or boosting in favor of a broader and more musical Q filter. After extensive experimentation, Perkins was able to identify capacitor and resistor values that would give the equalizer an additional 6 dB of control (±15 dB) without excessive narrowing of the filter bandwidth.
Features:
- Ultra-clean sound, low noise level
- 12 Onyx microphone preamplifiers with ample headroom and gain up to 60 dB
- Full 18x4 USB recording at up to 24-bit/96 kHz
- Record stereo mix directly to SD card, as well as play back music files
- Professional, customizable effects
- Onyx Studio Command – a full-color display that simplifies control of the effects block and SD card
- Perkins British Style equalizer provides classic sounds of the 60s and 70s with modern quality and precision
- Stream music directly to a channel via Bluetooth
- Improved built-in power supply, eliminating the possibility of electrical interference in the mixer's audio paths
- Option for rack installation using optional mounts
Package includes:
- Mixer console
- Power cable
- Documentation and software.
