Headphone amplifier with DAC
ddHiFi x Dr.Head TC35M2 USB-C - 3.5 mm

Product code: 144172
no reviews
AED 169
Delivery from the supplier's remote warehouse.
We will contact you within 48 hours to clarify the delivery time.

Description

Reviews (0)

Description

ddHiFi x Dr.Head TC35M2

The ddHiFi x Dr.Head TC35M2 is a new version of a headphone DAC and amplifier in adapter format, created in collaboration between two professional audio brands. This compact device combines advanced technologies to provide superior listening quality tailored to your preferences.

Features:

  • Headphone amplifier chip: ES9603Q;
  • Supports PCM 32-bit / 384 kHz;
  • Power output: 45+45 mW (32 ohms);
  • Portable DAC with 3.5mm jack;
  • Input: USB-C.

The TC35M2 model is designed for the convenience of wired headphone users. Compared to the previous generation, this 2nd generation features improved housing quality and increased durability of the connector, making it more long-lasting and reliable.

Headphone Connection Detection Function

The headphone jack is equipped with a connection detection function that allows you to determine if headphones are connected. The TC35M2 also supports a four-pole 3.5mm headphone cable, enabling you to answer phone calls and control your music playback.

CS43131 DAC

The TC35M2 supports popular music applications such as Apple Music, QQ Music, Netease Cloud Music, Sony Lossless Music, and more. While most lossless music formats offered by these applications support frequencies of 44.1 kHz, 96 kHz, or 192 kHz, the TC35M2 supports PCM decoding up to 384 kHz.

Equipped with an autonomous decoding chip and operational amplifier chip, the TC35M2 ensures stable performance and output power, compatible with most 3.5mm headphones available on the market. It is suitable for connecting headphones with a 3.5mm jack to devices supporting USB-C. The power output of the ddHiFi TC35M2 is 45+45 mW with 32-ohm headphones. It uses the CS43131 chip as the DAC and the ES9603Q chip as the amplifier.

What's Included:

  • ddHiFi adapter;
  • Documentation.
Reviews (0)

There are no reviews for this product yet.

Characteristics

Characteristics

Brand
Connector (left)
3.5mm jack female, USB-C
Connector (right)
3.5mm jack female, USB-C
Headphone output
3.5mm jack
Output connectors
3.5mm jack
Power output

This is the useful power developed by the amplifier in the load resistance. Amplifiers are usually characterized by the highest power that can be obtained at the output, provided that the distortion does not exceed the specified permissible value. This power is called the output power of the amplifier.

Glossary of terms
0.45
DAC chip

The chip used for digital-to-analog conversion

Glossary of terms
ES9603Q
DAC bit depth, bits
32
Sampling rate, kHz

The sampling frequency of a time-continuous signal during its sampling

Glossary of terms
384
Signal-to-noise ratio, dB

The higher signal-to-noise ratio, the clearer sound and the bigger the dynamic range provided by the system

Glossary of terms
112
Powered by USB
yes
Connecting to a computer via USB
yes
The lowest frequency, Hz
20
The highest frequency, kHz

The upper limit of the frequencies reproduced by the device. The human ear hears the standard frequency range: 20 Hz – 20000 Hz.

Glossary of terms
20
Color
Form factor
portable
Input connectors
USB-C
Internal DAC
yes
Material
aluminum
Playback via USB
yes

Playing music files via USB

Словарь терминов
Circuit design
operational
Power, W
0.45
Depth, mm
9
Height, mm
14
Width, mm
17
Weight, g
4
Country of origin

The country of origin may differ from the declared one. Production facilities may be located in several states. All brand factories operate according to general standards, and finished products undergo appropriate control.

China
Service life, months
24
Warranty, months
12
Show all characteristicsShow fewer characteristics
