Headphone amplifier with DAC
ddHiFi TC35C Lightning

Product code: 124733
no reviews
AED 225
Delivery
Pickup in Dubai:
1 store, Calculating...
Delivery (Dubai):
Calculating...
AVAILABILITY
  • A lot of goods
  • Enough product
  • Product is running out
Media City, Business Central Tower B
Online store (Dubai)
In stock

Description

Reviews (0)

Description

The ddHiFi TC35C is a portable converter that transforms digital audio into analog signals while also incorporating a headphone amplifier. This device features a headphone audio output and a USB input (Lightning) that enables you to connect headphones with a 3.5 mm connector to Lightning-compatible devices.

Equipped with the advanced ALC5686 chip, it offers exceptional performance with a high signal-to-noise ratio of 120 dB and minimal harmonic distortion of 0.002%. These specifications ensure optimal sound transmission, low power consumption, and stable playback switching.

Despite its compact size, the ddHiFi TC35C offers a multitude of capabilities. It supports Hi-Res Audio playback up to 32-bit / 384 kHz, effectively replacing bulky amplifiers. It can be used as a source for desktop computers, laptops, or tablets to enhance audio quality.

A notable feature is its high-precision volume control, offering smooth adjustment with precise increments. This allows for fine-tuning of the output level, distinguishing it from traditional analog volume controls.

Reliability and durability are key aspects of this device. It features an all-metal design that eliminates the common problem of wear and tear experienced with cables that have built-in adapters. Additionally, the metal case effectively shields against electromagnetic interference, ensuring lossless sound transmission.

Other notable features include an updated aluminum housing that reduces weight by 2 grams compared to its predecessor. This portable DAC includes a 3.5 mm jack and supports headphones with an impedance range of 16 to 200 Ohms. It also includes an automatic shutdown feature when the cable is unplugged, a fully shielded housing, and support for 4-pole cables for control. It is Apple MFI certified and renowned for its compactness, weighing only 3.5 g.

Overall, the ddHiFi TC35C is a comprehensive solution for high-quality audio, conveniently combining a portable DAC, headphone amplifier, and various useful features.

Reviews (0)

There are no reviews for this product yet.

Characteristics

Characteristics

Brand
Conductor material
copper
Connector (left)
3.5mm jack female, Lightning
Connector (right)
3.5mm jack female, Lightning
Headphone output
3.5mm jack
Output connectors
3.5mm jack
Power output

This is the useful power developed by the amplifier in the load resistance. Amplifiers are usually characterized by the highest power that can be obtained at the output, provided that the distortion does not exceed the specified permissible value. This power is called the output power of the amplifier.

Glossary of terms
0.03
DAC chip

The chip used for digital-to-analog conversion

Glossary of terms
ALC5686
DAC bit depth, bits
32
Sampling rate, kHz

The sampling frequency of a time-continuous signal during its sampling

Glossary of terms
384
Signal-to-noise ratio, dB

The higher signal-to-noise ratio, the clearer sound and the bigger the dynamic range provided by the system

Glossary of terms
120
Powered by USB
yes
The lowest frequency, Hz
20
The highest frequency, kHz

The upper limit of the frequencies reproduced by the device. The human ear hears the standard frequency range: 20 Hz – 20000 Hz.

Glossary of terms
20
Color
Form factor
portable
Input connectors
Lightning
Internal DAC
yes
Material
aluminum
Playback via USB
yes

Playing music files via USB

Словарь терминов
Circuit design
operational
Depth, mm
16.6
Height, mm
9.6
Width, mm
16.2
Weight, g
3.5
Country of origin

The country of origin may differ from the declared one. Production facilities may be located in several states. All brand factories operate according to general standards, and finished products undergo appropriate control.

China
Service life, months
24
Warranty, months
12
